The OP275GSZ is a high-performance audio operational amplifier (op-amp) designed by Analog Devices Inc., a leader in the semiconductor industry. This op-amp is known for its excellent sound quality and is widely used in professional audio equipment, including mixing consoles, preamplifiers, and other high-fidelity audio applications.

Key Features

• Dual Op-Amp Design: The OP275GSZ features a dual op-amp configuration, making it ideal for stereo audio applications or two separate audio channels in a single package.
• Low Noise Performance: With its low noise specifications, the OP275GSZ ensures a clear and undistorted audio signal, which is crucial for high-quality audio reproduction.
• High Output Drive Capability: This op-amp can drive 600-ohm loads, which allows it to perform well in professional audio environments where such loads are common.
• Wide Bandwidth: The OP275GSZ offers a wide bandwidth of 9MHz, which is more than sufficient for audio applications, ensuring that the full spectrum of audible frequencies is accurately amplified.
• Low Total Harmonic Distortion (THD): The op-amp boasts a low THD, which minimizes distortion of the audio signal, preserving the integrity of the original sound.

Applications

The versatility of the OP275GSZ allows it to be used in a variety of audio applications. It is particularly suited for:

• Professional audio mixing and recording equipment
• High-fidelity preamplifiers and power amplifiers
• Active filters and crossover networks for speakers
• Audio signal processing equipment

Technical Specifications

The OP275GSZ operates within a supply voltage range of ±5V to ±15V, providing flexibility in various circuit designs. It comes in an 8-lead SOIC package, which is compact and suitable for space-constrained applications. The operating temperature range of -40°C to +85°C ensures reliable performance across a wide range of environmental conditions.

For those seeking an op-amp that delivers exceptional audio performance with minimal distortion and noise, the OP275GSZ from Analog Devices Inc. is an excellent choice that combines quality, reliability, and versatility.
