Product Overview: HMC647LP6ETR by Analog Devices Inc.

The HMC647LP6ETR is a high-performance passive double-balanced mixer from Analog Devices Inc., designed to offer excellent RF performance in a compact 6x6mm QFN package. This versatile device is a perfect solution for applications requiring frequency conversion, such as in wireless infrastructure, microwave radios, and test equipment.

Key Features

• Frequency Range: The mixer operates over a wide frequency range, with an RF and LO frequency from 24 GHz to 32 GHz and an IF frequency from DC to 5 GHz, providing flexibility for various high-frequency applications.
• Conversion Loss: It boasts a low conversion loss, typically 9 dB, which ensures efficient signal conversion and minimal signal degradation.
• LO/RF Isolation: The device offers excellent LO to RF isolation of 37 dB, which helps to minimize leakage between the local oscillator and the RF signal paths.
• Input IP3: With a high input third-order intercept point (IP3) of 25 dBm, the mixer is capable of handling high input power levels while maintaining linearity.
• Package: Encased in a compact 6x6mm QFN package, the HMC647LP6ETR is suitable for space-constrained applications without compromising on performance.

Applications

The HMC647LP6ETR is ideal for use in a range of high-frequency applications, including:

• Point-to-point and point-to-multipoint radios
• VSAT
• Test equipment and sensors
• Military and space
• Wireless infrastructure

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability, and the HMC647LP6ETR is no exception. This mixer is manufactured to the highest standards, ensuring consistent performance and durability for mission-critical applications.

With its combination of wide frequency range, low conversion loss, and excellent isolation, the HMC647LP6ETR from Analog Devices Inc. stands out as a robust and reliable mixer for sophisticated RF designs.
