The ADUM5201CRWZ-RL from Analog Devices Inc. is a high-performance, dual-channel digital isolator with integrated dc-to-dc converter. This robust component is designed to ensure reliable signal isolation in demanding industrial and commercial applications. The device employs Analog Devices' proprietary iCoupler® technology to provide isolation between the input and output sides, enhancing system safety and signal integrity.

Key Features

• Isolation Technology: Utilizes iCoupler® technology to offer bidirectional isolation for data channels.
• Integrated DC-to-DC Converter: Features an integrated, fully isolated dc-to-dc converter, which provides regulated power to the isolated side, eliminating the need for a separate isolated power supply.
• High Data Rate: Supports data rates up to 25 Mbps, ensuring high-speed data communication with minimal signal delay.
• High Isolation Voltage: Certified to provide up to 2500 Vrms of isolation for 60 seconds, making it suitable for high voltage applications where electrical safety is a concern.
• Low Emissions: Designed with low EMI emissions in mind, making it suitable for noise-sensitive applications.
• Wide Temperature Range: Operates effectively across a broad temperature range from -40°C to +125°C, accommodating extreme operating conditions.

Applications

The ADUM5201CRWZ-RL is ideal for use in a variety of applications, including:

• Industrial automation and process control
• Medical equipment with stringent safety requirements
• Isolated sensor interfaces and data acquisition systems
• Power supply control and monitoring
• Motor control circuits

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality and reliability, and the ADUM5201CRWZ-RL is no exception. The device is available in a 16-lead SOIC wide body package and is RoHS compliant. With its superior isolation capabilities and integrated power solution, the ADUM5201CRWZ-RL stands out as a top choice for designers seeking to enhance the safety and performance of their systems.
