ADM2484EBRWZ - Isolated RS-485/RS-422 Transceiver by Analog Devices Inc.

The ADM2484EBRWZ is a robust, high-speed, fully isolated RS-485/RS-422 transceiver designed to provide efficient communication in industrial environments. Manufactured by Analog Devices Inc., a leader in high-performance analog technology, this transceiver is engineered to facilitate reliable data transmission over long distances and in noisy conditions.

Key Features:

• Signal Isolation: With integrated iCoupler® technology, the ADM2484EBRWZ offers galvanic isolation up to 2.5 kV RMS, which helps in protecting against high voltage spikes and ground loops in harsh industrial settings.
• Data Rates: Capable of supporting data rates up to 16 Mbps, this transceiver is suitable for high-speed data communication applications.
• Thermal Shutdown Protection: It includes a thermal shutdown feature that prevents the device from overheating, ensuring long-term reliability and safety.
• ESD Protection: The device has an electrostatic discharge (ESD) protection level of ±15 kV on the transceiver bus pins, safeguarding it from the potential damage caused by ESD events.
• Half-Duplex Operation: It operates in a half-duplex mode, allowing for bidirectional communication over a single pair of wires, which helps reduce the complexity and cost of the cabling.

Applications:

The ADM2484EBRWZ is ideal for a wide range of applications that require reliable data transmission and isolation, such as:

• Industrial field buses
• Factory automation
• Building automation
• Process control systems

Product Specifications:

This transceiver is available in a wide body, 16-lead SOIC package (RW-16), ensuring compatibility with standard PCB layouts. It operates over a temperature range of -40°C to +85°C, making it suitable for various environmental conditions. The ADM2484EBRWZ also meets stringent industrial standards for isolation and reliability, making it a trusted choice for critical industrial communication networks.

With its combination of high-speed data transfer, robust isolation, and protection features, the ADM2484EBRWZ from Analog Devices Inc. stands out as a high-performance solution for isolated communication in demanding applications.
