The ADM101EARMZ-REEL7 is a high-performance, low-power, RS-232 and V.28/V.24 communication device that meets the requirements of the EIA-232E and ITU-T V.28 specifications. Manufactured by Analog Devices Inc., a leader in high-performance semiconductors, this product is designed for modern communication applications.

Key Features

• Interface Type: RS-232
• Data Rate: Up to 460 kbps
• Operating Voltage Range: 3.0V to 5.5V
• Number of Drivers/Receivers: 1/1
• Low Power Shutdown: Yes
• Package: MSOP-10
• Mounting Type: Surface Mount
• Temperature Range: -40°C to +85°C
• RoHS Compliant: Yes

Product Details

The ADM101EARMZ-REEL7 is presented in a compact MSOP-10 package and is part of a reel, making it suitable for automated assembly processes. It operates over a broad voltage range from 3.0V to 5.5V, which allows for flexibility in design and compatibility with a wide range of microcontrollers and processors.

With its enhanced electrostatic discharge (ESD) protection, this device ensures reliability and durability in harsh environments, making it an excellent choice for industrial and commercial applications. The integrated low power shutdown mode significantly reduces power consumption when not in active use, thereby extending battery life in portable solutions.

The ADM101EARMZ-REEL7 also supports a data rate of up to 460 kbps, providing efficient data transfer for high-speed communication links. Its operating temperature range of -40°C to +85°C guarantees stable performance across various environmental conditions.

Applications

• Portable Instruments
• GPS Modules
• Data Cables
• Battery-Powered Devices
• Notebook, Subnotebook, and Palmtop Computers

This product is a reliable solution for designers seeking to implement RS-232 communication interfaces with minimal power consumption and robust protection features.
