The ADG788BCPZ is a high-performance, dual 2:1 multiplexer/demultiplexer manufactured by Analog Devices Inc., designed to deliver precision signal routing in various applications. This versatile component is part of the ADG788 series and is known for its low on-resistance and low crosstalk, making it an excellent choice for high-frequency data streams and analog signals.

Key Features

• Low Voltage Operation: The ADG788BCPZ operates at a single supply voltage ranging from +1.8V to +5.5V, making it suitable for battery-powered devices and low-voltage systems.
• Low On-Resistance: It boasts a typical on-resistance of just 4 ohms, which minimizes signal attenuation and ensures high signal integrity.
• Low Crosstalk: The device's design minimizes signal interference, providing cleaner and more accurate signal routing.
• Fast Switching Times: With t_ON and t_OFF times of typically 0.5ns, the ADG788BCPZ can handle high-speed signals with ease.
• Dual 2:1 Multiplexer/Demultiplexer Configuration: This configuration allows for flexible signal routing options within a circuit.
• ESD Protection: The device features input and output protection against electrostatic discharge, enhancing its robustness for industrial applications.

Applications

The ADG788BCPZ is suitable for a wide range of applications, including but not limited to:

• Audio and Video Routing
• Data Acquisition Systems
• Communication Systems
• Relay Replacement
• Automatic Test Equipment

Package and Quality

The component is offered in a compact 16-lead LFCSP (Lead Frame Chip Scale Package) that is designed for space-saving on the PCB. The ADG788BCPZ meets stringent quality standards, ensuring reliability and performance consistency for critical applications.

Conclusion

The ADG788BCPZ from Analog Devices Inc. represents a blend of high-performance specifications and versatile functionality. Its low-voltage operation, fast switching, and robust design make it an ideal choice for designers looking to optimize their signal routing solutions in compact and energy-efficient electronic systems.
