The ADG787BCBZ-500RL7 is a state-of-the-art CMOS analog multiplexer/demultiplexer from Analog Devices Inc., renowned for its high-performance semiconductor solutions. This component is part of a family of monolithic CMOS devices designed to provide high-speed, low-power switching of analog and digital signals.

Key Features

• Low On-Resistance: The device features a low on-resistance (RON) that typically stands at 4 ohms, ensuring minimal signal distortion and power loss.
• Single Supply Operation: It operates from a single 2.5V to 5.5V power supply, making it versatile for various applications and simplifying power management.
• Dual 2:1 Mux/Demux Configuration: The ADG787BCBZ-500RL7 offers a dual 2:1 multiplexer/demultiplexer configuration, providing flexibility in routing signals in complex circuits.
• Low Power Consumption: With its CMOS construction, the device consumes very low power, which is crucial for battery-powered and energy-efficient systems.
• High Switching Speed: The device boasts fast switching times, with turn-on and turn-off times typically less than 20 ns, catering to applications requiring high-speed signal processing.
• ESD Protection: It includes enhanced ESD (Electrostatic Discharge) protection, which safeguards the device against static damage during handling and operation.

Applications

The ADG787BCBZ-500RL7 is suitable for a myriad of applications, including but not limited to:

• Data Acquisition Systems
• Communication Systems
• Audio and Video Switching
• Relay Replacement
• Automotive Infotainment Systems

Package and Quality

The product is available in a compact 10-lead MSOP (Mini Small Outline Package) that is RoHS compliant, minimizing the PCB space required. It is also provided in tape and reel form to facilitate automated assembly processes. The part number ADG787BCBZ-500RL7 denotes that the device is provided in a 500-unit reel, suitable for high-volume production environments. Analog Devices Inc. maintains rigorous quality standards, ensuring that the ADG787BCBZ-500RL7 meets the requirements of even the most demanding applications.
