The ADG749BKSZ is a high-performance, monolithic CMOS switch fabricated by Analog Devices Inc. It is designed to deliver precision and reliability for a wide range of applications, including data acquisition systems, communication systems, and medical equipment. This switch is part of the ADG749 series and comes in a compact 6-lead SC70 package, making it ideal for space-constrained applications.

Key Features:

• Wide Operating Voltage Range: The device operates from a single 1.8V to 5.5V power supply, providing versatility across different power environments.
• Low On Resistance: The switch features a low on resistance of typically 0.4 ohms, ensuring minimal signal distortion and power loss.
• Fast Switching Times: With t_ON of 20 ns and t_OFF of 10 ns, the ADG749BKSZ provides rapid switching, which is crucial for high-speed signal routing.
• Low Power Consumption: The device boasts a low power consumption, with a leakage current of only 1 nA at 25°C, making it suitable for battery-powered devices.
• High ESD Protection: It offers excellent electrostatic discharge (ESD) protection, ensuring robust performance in environments prone to static electricity.

Applications:

• Sample-and-Hold Circuits
• Audio and Video Signal Routing
• Communication Systems
• Data Acquisition Systems
• Medical Equipment

The ADG749BKSZ is designed with a break-before-make switching action, which prevents momentary shorting when switching channels. This feature is particularly important in multiplexing applications where signal integrity is paramount. Additionally, the device's low charge injection reduces the impact on the signal during the transition, making it ideal for precise analog applications.

Overall, the ADG749BKSZ from Analog Devices Inc. is a versatile, high-performance switch that offers reliability and precision, making it a top choice for engineers and designers in various fields seeking efficient and space-saving switching solutions.
