Product Overview: ADG712BRU-REEL7

The ADG712BRU-REEL7 is a high-performance CMOS analog multiplexer from Analog Devices Inc., renowned for its precision in signal routing for data acquisition systems. This component is a part of the robust ADG712 series, characterized by its low power consumption and wide operational voltage range, making it an excellent choice for battery-powered and portable devices.

Key Features

• Channel Configuration: The device offers a 4-channel dual configuration, providing flexibility in connecting multiple input signals to a single output.
• Low On Resistance: With a typical on resistance of just 4 ohms, the ADG712BRU-REEL7 ensures minimal signal attenuation, which is crucial for maintaining signal integrity.
• Single/Dual Supply Operation: It operates effectively with a single supply range of +3 V to +5 V or a dual supply range of ±2.5 V to ±5.5 V, accommodating a variety of power environments.
• Low Power Consumption: The device boasts a low power consumption, with a typical power dissipation of less than 0.01 µW, making it highly efficient for power-sensitive applications.
• High-Speed Switching: Fast transition times with a t_ON of 30 ns and a t_OFF of 20 ns, enable rapid signal switching, beneficial for high-frequency signal processing.
• Enhanced Durability: Packaged in a robust TSSOP-16 package, the ADG712BRU-REEL7 is designed for durability and reliability in various applications.

Applications

The ADG712BRU-REEL7 is versatile and can be used in a wide array of applications, including:

• Data acquisition systems
• Communication systems
• Audio and video routing
• Relay replacement
• Industrial control systems

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the ADG712BRU-REEL7 is no exception. It is provided in a tape and reel format, facilitating efficient assembly during the manufacturing process. With its precision performance and reliable design, the ADG712BRU-REEL7 is an excellent choice for designers looking to enhance their system's signal routing capabilities with a trusted component.
