Analog Devices Inc. ADG411BRUZ Precision Analog Switch

The ADG411BRUZ is a high-performance, precision monolithic analog switch from Analog Devices Inc., designed to deliver exceptional signal accuracy and operational efficiency for a wide range of applications. This product is part of a series of low charge injection, fast, CMOS switches that significantly reduce power consumption without sacrificing performance.

Encased in a compact TSSOP-16 package, the ADG411BRUZ offers four independently selectable single-pole, single-throw (SPST) switches, making it an ideal choice for multiplexing and signal routing applications that require low on-resistance and low off-leakage currents. The device operates from a single 15 V supply or from dual ±15 V supplies for added flexibility in various circuit configurations.

Key Features:

• Low On-Resistance: The on-resistance profile of the ADG411BRUZ is typically below 35 ohms, ensuring minimal signal distortion and power loss across the switch.
• Low Charge Injection: With its low charge injection design, the switch minimizes errors and disturbances in precision applications, preserving signal fidelity upon switching events.
• Single or Dual Supply Operation: The device can be powered by a single supply ranging from +10 V to +30 V or a dual supply of ±5 V to ±15 V, offering versatility in system design.
• Low Power Consumption: The CMOS construction ensures that the ADG411BRUZ consumes minimal power, making it suitable for battery-powered and portable devices.
• Fast Switching Times: With t_ON of 150 ns and t_OFF of 100 ns, the switch operates swiftly, facilitating high-speed signal processing and reducing transition times.
• Enhanced Durability: The device is built to withstand continuous operation, ensuring a long operational lifespan within the specified temperature ranges.

Applications for the ADG411BRUZ are diverse and include data acquisition systems, communication systems, audio and video signal routing, and industrial automation. Its precision switching capabilities make it an essential component for designers looking to achieve high accuracy and reliability in their electronic systems.

As a product from Analog Devices Inc., a leader in high-performance analog technology, the ADG411BRUZ represents a blend of innovation, quality, and performance, backed by rigorous testing and a commitment to excellence in electronic design.
