ADG1409YRUZ High-Performance Analog Multiplexer from Analog Devices Inc.

The ADG1409YRUZ is a high-performance, monolithic CMOS analog multiplexer from Analog Devices Inc., a leading global manufacturer of high-performance integrated circuits used in analog and digital signal processing applications. This product is part of their extensive range of switches and multiplexers that are designed to provide efficient solutions for routing analog signals in a wide array of electronic systems.

The ADG1409YRUZ offers four single-pole, single-throw (SPST) switches, providing an excellent signal routing solution for applications that require high signal integrity and low distortion. With a wide operating voltage range of ±5 V to ±16.5 V, or a single supply of 10 V to 16.5 V, this multiplexer is versatile enough to be integrated into various circuit configurations, making it ideal for use in data acquisition systems, communication systems, and audio/video signal routing.

One of the key features of the ADG1409YRUZ is its low on-resistance (typically 4.5 Ω), which remains flat over the full analog signal range. This characteristic ensures minimal signal attenuation and distortion, leading to higher fidelity in signal processing applications. Additionally, the multiplexer exhibits low charge injection, further preserving signal integrity during switching events.

The device also boasts fast switching times, with t_ON typically at 60 ns and t_OFF at 30 ns, allowing for rapid signal routing that is essential in high-speed data acquisition and processing systems. The ADG1409YRUZ comes with a built-in overvoltage protection feature that guards the device against momentary voltage spikes, enhancing the reliability and longevity of your system.

For ease of integration, this multiplexer is offered in a compact TSSOP-16 package, making it suitable for space-constrained applications. The ADG1409YRUZ is specified over the extended industrial temperature range of -40°C to +125°C, ensuring consistent performance in harsh environmental conditions.

In summary, the ADG1409YRUZ from Analog Devices Inc. is an exceptional choice for designers looking for a high-quality, reliable analog multiplexer that delivers excellent signal integrity, fast switching speeds, and robust protection features. Whether for industrial, communication, or consumer electronics, this multiplexer is engineered to meet the rigorous demands of modern electronic systems.
