The AD9251BCPZ-65 is a high-performance, dual-channel, 14-bit Analog-to-Digital Converter (ADC) from Analog Devices Inc., designed to deliver exceptional data acquisition performance in a compact package. It is a member of the renowned AD9251 family known for its precision and reliability in converting analog signals into digital data with a sampling rate of up to 65 MSPS (Mega Samples Per Second).

Key Features

• Resolution: 14-bit ADC offers fine granularity for a wide range of applications.
• Sampling Rate: Capable of sampling rates up to 65 MSPS, enabling high-speed data acquisition.
• Dual Channel: Features two ADCs in one package, providing simultaneous sampling and reduced system complexity.
• Low Power Consumption: Optimized for power-sensitive applications, ensuring efficient operation.
• Integrated Features: Comes with an on-chip voltage reference and sample-and-hold circuit, facilitating easier design integration.
• Serial LVDS Outputs: Utilizes low-voltage differential signaling for robust, high-speed data transfer.
• Flexible Power-Down Options: Offers various power-down modes for dynamic power management.

Applications

The AD9251BCPZ-65 is ideal for a broad array of applications that require high-speed and accurate data conversion. It is particularly well-suited for:

• Medical Imaging Systems
• Data Acquisition Systems
• Communications Infrastructure
• Radar and Satellite Antenna Arrays
• Instrumentation and Testing Equipment

Technical Specifications

Quality and Reliability

Analog Devices Inc. is committed to providing high-quality products. The AD9251BCPZ-65 is built to meet stringent industry standards, ensuring reliability and performance for critical applications.
