Analog Devices Inc. AD7789BRM Low Power, 24-bit Sigma-Delta ADC

The AD7789BRM from Analog Devices Inc. is a highly precise 24-bit Sigma-Delta Analog-to-Digital Converter (ADC) designed to offer exceptional performance with low power consumption. This component is particularly suited for applications requiring high-resolution measurement, such as industrial process control, instrumentation, and medical devices, where accuracy and power efficiency are critical.

The AD7789BRM operates on a single power supply ranging from 2.7V to 5.25V and features a very low current consumption of only 75 µA, making it an ideal choice for battery-powered and portable applications. The device comes in a compact 10-lead MSOP (Mini Small Outline Package), which allows for easy integration into space-constrained designs.

One of the standout features of the AD7789BRM is its on-chip, low-noise programmable gain amplifier (PGA), which provides gains ranging from 1 to 128. This allows the ADC to convert small differential input signals directly while maintaining a high dynamic range. The device also includes a power-down mode, further reducing the power consumption when the ADC is not in active conversion.

The AD7789BRM boasts an impressive signal-to-noise ratio (SNR) and low noise performance, ensuring accurate readings across its entire operating range. It supports a maximum input frequency of 10 Hz, making it suitable for low-speed, high-resolution applications. The ADC also offers a simple serial interface that is compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards, providing flexibility and ease of use in system design.

In addition to its technical capabilities, the AD7789BRM is known for its reliability and robustness, with features such as a self-calibration function on power-up and a system calibration feature that can be initiated by the user. This ensures long-term stability and accuracy of the measurement system without the need for regular manual calibration.

Overall, the AD7789BRM from Analog Devices Inc. is a top-tier ADC solution for designers who require the highest levels of precision and power efficiency in their data acquisition systems.
