AD7195BCPZ - High Precision, Low Noise Analog-to-Digital Converter

The AD7195BCPZ is a state-of-the-art, low noise, complete analog front end for high precision measurement applications. Manufactured by Analog Devices Inc., this 24-bit sigma-delta (σδ) Analog-to-Digital Converter (ADC) is notable for its exceptional noise performance and high data throughput. The AD7195BCPZ is an ideal choice for applications requiring high-resolution sensing and measurement, such as industrial process control, instrumentation, and medical devices.

Key Features:

• Resolution: 24-bit resolution provides high accuracy and fine detail in measurement.
• Data Output Rate: Programmable data output rates allow for flexibility in various applications.
• On-Chip Noise Reduction: Features an on-chip, low-pass filter that minimizes external noise interference.
• Multiple Input Channels: Supports up to 8 differential inputs or 15 single-ended inputs, making it versatile for multiplexed applications.
• Integrated Features: Includes an on-chip temperature sensor, reference, and clock generator for simplified system design.
• Interface: Serial interface compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards.
• Power Supply: Operates from a single 3 V or 5 V power supply, suitable for battery-powered devices and energy-efficient systems.
• Package: Available in a compact 28-lead LFCSP (Lead Frame Chip Scale Package) for reduced board space.

Applications:

• Industrial Process Control
• Weight Scales
• Pressure Measurement
• Medical and Scientific Instrumentation
• Chromatography
• Portable Instrumentation

The AD7195BCPZ is designed to offer a blend of precision, flexibility, and ease of integration, making it a top choice for engineers and designers who demand the highest quality in data acquisition systems. With its robust feature set and proven reliability, the AD7195BCPZ by Analog Devices Inc. sets the standard for ADC performance in challenging environments and precision applications.
