The AD1580BRTZ is a high-precision, low-power voltage reference from Analog Devices Inc., designed to ensure stability and accuracy in a wide range of applications. This device comes in a compact SOT-23 package, making it ideal for space-constrained applications.

Key Features

• Precision Voltage: The AD1580BRTZ offers a stable and precise 1.225V output, which is crucial for high-accuracy analog circuits.
• Low Power Consumption: With a quiescent current of just 60µA, this voltage reference minimizes power consumption, making it suitable for battery-powered devices.
• Wide Operating Range: It operates over a wide range of currents, from 50 µA to 10 mA, providing versatility in various applications.
• Temperature Stability: The device features excellent temperature stability, ensuring consistent performance over the industrial temperature range of -40°C to +85°C.
• Low Dropout Voltage: The AD1580BRTZ has a low dropout voltage, allowing it to maintain output regulation with minimal headroom above the output voltage, which is beneficial in low-voltage operations.

Applications

The AD1580BRTZ is suitable for a diverse range of applications, including:

• Battery-powered equipment
• Precision data acquisition systems
• Portable instrumentation
• Automotive electronics
• Industrial control systems

Quality and Reliability

Analog Devices Inc. is renowned for its commitment to quality, and the AD1580BRTZ is no exception. It is manufactured with the highest standards to ensure reliable performance in critical applications.

Ordering Information

The AD1580BRTZ is available for order with the option for bulk or custom packaging to meet various application requirements. For detailed information on pricing, availability, and shipping, please contact Analog Devices Inc. or authorized distributors.
