Product Overview: 101830-HMC400MS8 - Analog Devices Inc.

The HMC400MS8, from Analog Devices Inc., is a high-performance GaAs MMIC PHEMT Distributed Power Amplifier die that operates between DC to 15 GHz. This versatile amplifier is designed to offer excellent dynamic range through a combination of low noise figure and output power. It is an ideal component for a wide range of applications, including test instrumentation, military and space, broadband communications, and microwave radios.

Key Features

• Frequency Range: The HMC400MS8 operates effectively across a wide frequency range from DC to 15 GHz, making it highly suitable for various applications in different frequency bands.
• Output Power: It delivers +17 dBm of output power at 1 dB gain compression point, ensuring strong signal amplification for robust performance.
• Gain: With a high gain of 11 dB at 15 GHz, this amplifier can significantly boost signal levels.
• Power Added Efficiency: The device features a power-added efficiency (PAE) of 14%, which is beneficial for systems where efficiency is a critical parameter.
• Supply Voltage: It operates on a supply voltage of +8 V, making it compatible with standard power supply levels used in electronic circuits and systems.
• Package: The HMC400MS8 is offered in a compact MSOP8G package, which is convenient for space-constrained applications.
• RoHS Compliant: The product is RoHS compliant, ensuring adherence to environmental standards and regulations.

Applications

• Test and Measurement Instrumentation
• Military and Space Components
• Broadband Communications Systems
• Microwave Radios and VSAT

The HMC400MS8 is a testament to Analog Devices Inc.'s commitment to providing high-quality, reliable components for the most demanding electronic applications. With its broad frequency range, high gain, and solid output power, this amplifier is engineered to meet the needs of professionals seeking performance and reliability in their RF and microwave systems.

For more detailed specifications and application support, customers are encouraged to contact Analog Devices Inc. or visit their official website to access technical documents and support resources.
