77311-118-05LF Real Image
Same model may have multiple batches, images only for reference.

77311-118-05LF

Part No 77311-118-05LF
Manufacturer Amphenol
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 5POS 2.54MM / Connector Header Through Hole 5 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Amphenol ICC (FCI)
Series BERGSTIK®
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 5
Number of Rows 1
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.230" (5.84mm)
Contact Length - Post 0.120" (3.05mm)
Overall Contact Length 0.450" (11.43mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold or Gold, GXT™
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Thermoplastic
Temperature Range - Operating -65°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A per Contact
Contact Finish Thickness - Post 78.7µin (2.00µm)
Base Product Number 77311
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 609-4794,77311-118-05LF-ND
Standard Package 500
Win Source Part Number 1005789-77311-118-05LF
Ultra Librarian 3D Model Ultra Librarian 77311-118-05LF CAD Model

Description

The Amphenol ICC (FCI) 77311-118-05LF is a board-to-board connector with a pitch of 0.100" (2.54mm).

  • Pitch: 0.100" (2.54mm)
  • Positions: 5
  • Contact Type: Male Pin
  • Operating Temperature: -65°C ~ 125°C
  • Current Rating: 3A per contact
  • Applications: Telecommunications and Power Supplies
  • Quantity per Package: 500
  • Production Lead Time: 45 weeks
