AME7805AJCS AME, Inc
Same model may have multiple batches, images only for reference.

AME7805AJCS

Part No AME7805AJCS
Manufacturer AME, Inc
Catalog HOT - SALES and EOL Components (0 - A)
Description 1A POSITIVE LINEAR REGULATOR
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer AME, Inc
Win Source Part Number 178440-AME7805AJCS
Popularity Low
Supply and Demand Status Balance
Family Name AME7805A
Introduction Date December 30, 2004
ECCN EAR99
Estimated EOL Date Not Applicable
Ultra Librarian 3D Model Ultra Librarian AME7805AJCS CAD Model

Description

Product Overview

The AME7805AJCS is a highly efficient, low dropout voltage regulator specifically designed to provide a stable 5V output from a varied input voltage range.

Features and Benefits

  • Low dropout voltage for high efficiency
  • Thermal protection to prevent overheating
  • Short-circuit protection to enhance durability
  • Compact size for easy integration in small devices

Applications

  • IoT devices
  • Embedded systems
  • Portable electronics
  • Battery-powered devices

Additional Details

This voltage regulator is ideal for use in environments where space is limited but efficiency and reliability are critical.
