Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - FPGAs (Field Programmable Gate Array)
Mfr AMD
Series Kintex® UltraScale™
Package Tray
Product Status Active
Programmable Not Verified
Number of LABs/CLBs 30300
Number of Logic Elements/Cells 530250
Total RAM Bits 21606000
Number of I/O 520
Voltage - Supply 0.922V ~ 0.979V
Mounting Type Surface Mount
Temperature Range - Operating 0°C ~ 100°C (TJ)
Package / Case 1156-BBGA, FCBGA
Supplier Device Package 1156-FCBGA (35x35)
Base Product Number XCKU040
Standard Package 1 pcs
MSL Level 4 (72 Hours)
REACH Status REACH Unaffected
ECCN 3A991D
HTSUS 8542.39.0001
Win Source Part Number 843851-XCKU040-2FFVA1156E
Ultra Librarian 3D Model Ultra Librarian XCKU040-2FFVA1156E CAD Model

Description

The 843851-XCKU040-2FFVA1156E is an integrated circuit (IC) belonging to the Kintex UltraScale series of embedded FPGAs (Field Programmable Gate Array) from AMD.

  • Package Type: Tray
  • Standard Package Quantity: 1 piece
  • I/O Pins: 520
  • Programmable: Yes
  • LABs/CLBs: 30,300
  • Logic Elements/Cells: 530,250
  • Total RAM Size: 21,606,000 bits
  • Voltage Supply Range: 0.922V to 0.979V
  • Mounting Type: Surface Mountable
  • Package/Case: 1156-BBGA, FCBGA
  • Operating Temperature Range: 0°C to 100°C
  • ECCN Classification: 3A991D
  • Product Status: Active
