AON7246

Name: AON7246
Brand: Alpha & Omega Semiconductor Inc.
SKU: 562300
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	AON7246
Manufacturer	Alpha & Omega Semiconductor Inc.
Catalog	FETs - Single
Description	Trans MOSFET N-CH 60V 34.5A 8-Pin DFN-A EP T/R / 60V N-Channel MOSFET \| MOSFET N-CH 60V 10A 8DFN
Datasheet	AON7246 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Alpha & Omega Semiconductor Inc.
Packaging	Reel
Status	Obsolete
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	60V
Id - Continuous Drain Current	10A, 34.5A
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Maximum) at Id, Vgs	15mOhm at 10A, 10V
Gate Source Voltage(th) (Maximum) at Id	2.5V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	25nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	1610pF at 30V
Power Dissipation (Maximum)	3.1W, 34.7W
Temperature Range - Operating	-55°C ~ 150°C
Mounting Style	SMD
Supplier Device Package	8-DFN (3x3)
Manufacturer Package	8-PowerVDFN
Manufacturer Pack Quantity	1
MSL Level	1 (Unlimited)
Win Source Part Number	1144988-AON7246
Manufacturer Homepage	www.aosmd.com
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	AON7246
Introduction Date	September 26, 2011
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian AON7246 CAD Model

Alternative Products

Description

The AON7246 is an N-channel MOSFET transistor manufactured by Alpha & Omega Semiconductor Inc. It has a Win Source Part Number of 1144988 and is a popular product with high popularity.

Drain-Source Breakdown Voltage: 60V
Maximum Continuous Drain Current: 10A
Rds On (Maximum) @ Id, Vgs: 15mOhm @ 10A, 10V
Gate Charge (Qg) (Maximum) @ Vgs: 25nC @ 10V
