ACS770LCB-050B-PFF-T Real Image ACS770LCB-050B-PFF-T real image21251 ACS770LCB-050B-PFF-T Real Image
Same model may have multiple batches, images only for reference.
ACS770LCB-050B-PFF-T Real Image ACS770LCB-050B-PFF-T real image21251 ACS770LCB-050B-PFF-T Real Image
ACS770LCB-050B-PFF-T Real Image ACS770LCB-050B-PFF-T real image21251 ACS770LCB-050B-PFF-T Real Image
Same model may have multiple batches, images only for reference.

ACS770LCB-050B-PFF-T

Part No ACS770LCB-050B-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Sense Transformers
Description 4.1 μs output rise time in response to step input current | SENSOR CURRENT HALL 50A AC/DC
Datasheet
ACS770LCB-050B-PFF-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Tube
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 50A
Output Ratiometric, Voltage
Sensitivity 40mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±0.6%
Supply Voltage (V) 5V
Response Time 4.6μs
Maximum Supply Current 15mA
Temperature Range - Operating -40°C ~ 150°C
Polarization Bidirectional
Mounting Style Through Hole
Manufacturer Package 5-CB Formed Leads, PFF
Supplier Device Package 5-CB Module
Manufacturer Pack Quantity 34
MSL Level 1 (Unlimited)
Win Source Part Number 758564-ACS770LCB-050B-PFF-T
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ACS770LCB-050B-PFF-T CAD Model

Description

The ACS770LCB-050B-PFF-T is a Hall Effect, Open Loop current sensor from Allegro MicroSystems.

  • Polarization: Bidirectional
  • Sensitivity: 40mV/A
  • Current Measurement: Up to 50A (AC/DC)
  • Output Type: Ratiometric, Voltage
  • Linearity: ±1%
  • Accuracy: ±0.6%
  • Response Time: 4.6μs
  • Frequency Range: DC to 120kHz
  • Mounting Type: Through Hole
  • Package: 5-CB module with formed leads
  • Operating Temperature: -40°C to 150°C
  • Maximum Supply Current: 15mA
