AM2D-1224DH30Z

Name: AM2D-1224DH30Z
Brand: AIMTEC
SKU: 1346964
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	AM2D-1224DH30Z
Manufacturer	AIMTEC
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-24V 2W / Isolated Module DC DC Converter 2 Output -24 ~ 24V -24V 42mA, 42mA 10.8V - 13.2V Input
Datasheet	AM2D-1224DH30Z Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	aimtec
Series	AM2D-Z (2W)
Package	Tube
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	10.8V
Voltage - Input (Max)	13.2V
Voltage - Output 1	-24 ~ 24V
Voltage - Output 2	-24V
Current - Output (Max)	42mA, 42mA
Power (Watts)	2 W
Voltage - Isolation	3 kV
Applications	ITE (Commercial)
Temperature Range - Operating	-40°C ~ 85°C
Efficiency	82%
Mounting Type	Through Hole
Package / Case	7-SIP Module
Size / Dimension	0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
Approval Agency	CE
Base Product Number	AM2D
Standard Package	20
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	1346964-AM2D-1224DH30Z
Ultra Librarian 3D Model	Ultra Librarian AM2D-1224DH30Z CAD Model

Alternative Products

Description

The aimtec AM2D-Z (2W) series is an isolated module type of power supply that is board-mounted.

Size Dimension: 0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
Application: ITE (Commercial)
Package Quantity: 20
Power: 2 W
Voltage Isolation: 3 kV
Number of Outputs: 2
Maximum Output Current: 42mA
Voltage Input: 10.8V to 13.2V
Voltage Output: -24 ~ 24V and -24V
Efficiency: 82%
Production Lead Time: 21 weeks
