N2550-6002-RB

Name: N2550-6002-RB
Brand: 3M
SKU: 790416
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	N2550-6002-RB
Manufacturer	3M
Catalog	Rectangular Connectors
Description	CONN HEADER 50 POS STRGHT GOLD / Conn Shrouded Header (4 Sides) HDR 50 POS 2.54mm Solder ST Top Entry Thru-Hole
Datasheet	N2550-6002-RB Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Connectors, Interconnects
Manufacturer	3M
Series	2500
Packaging	Bulk
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Style	Board to Board or Cable
Shrouding	Shrouded - 4 Wall
Number of Positions	50
Number of Positions Loaded	All
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Style	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.243" (6.17mm)
Contact Length - Post	0.112" (2.84mm)
Insulation Height	0.390" (9.91mm)
Contact Shape	Square
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	30μin (0.76μm)
Contact Finish - Post	Tin
Contact Material	Copper Alloy
Insulation Material	Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features	Keying Slot
Operating Temperature Range	-55°C ~ 105°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating	1.75A
Contact Finish Thickness - Post	200μin (5.08μm)
Win Source Part Number	790416-N2550-6002-RB
Popularity	Medium
Supply and Demand Status	Balance
Family Name	2500
Introduction Date	November 07, 2008
ECCN	EAR99
Country of Origin	United States of America
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian N2550-6002-RB CAD Model

Description

The 2500 series connector is a header type connector designed for use in connecting electrical devices.

Positions: 50
Pitch: 0.100” (2.54mm)
Shrouding: 4 walls
Mounting Style: through hole
Temperature Range: -55°C ~ 105°C
Keying: keying slot
Contact Finish: gold, 30μin (0.76μm)
Packaging: bulk
Manufacturer: 3M
