Same model may have multiple batches, images only for reference.
XC7Z100-2FFG1156I Real Image
Same model may have multiple batches, images only for reference.

XC7Z100-2FFG1156I

Part No XC7Z100-2FFG1156I
Manufacturer Xilinx Inc.
Catalog Embedded - System On Chip (SoC)
Description IC SOC CORTEX A-9 ZYNQ7 1156BGA / FPGA Kintex-7 Family 444000 Cells 28nm Technology 1156-Pin FCBGA Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Xilinx Inc.
Series Zynq-7000
Packaging Tray
Architecture MCU, FPGA
Core Processor Dual ARM Cortex-A9 MPCore with CoreSight
MCU RAM 256KB
Peripherals DMA
Connectivity CAN, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Speed 800MHz
Primary Attributes Kintex-7 FPGA, 444K Logic Cells
Operating Temperature Range -40°C ~ 100°C (TJ)
Package 1156-BBGA, FCBGA
Manufacturer Package 1156-FCBGA (35x35)
Number of I/O 250
Win Source Part Number 799982-XC7Z100-2FFG1156I
Popularity Medium
Supply and Demand Status Limited
Family Name XC7Z100
ECCN 3A991.d
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian XC7Z100-2FFG1156I CAD Model

Description

The XC7Z100-2FFG1156I is a Zynq-7000 series integrated circuit manufactured by Xilinx Inc.

  • Operating Temperature Range: -40°C to 100°C (TJ)
  • Processor: Dual ARM Cortex-A9 MPCore with CoreSight
  • Speed: 800MHz
  • Package: 1156-BBGA, FCBGA
  • Mounting: SMD
  • I/Os: 250
  • Connectivity: CAN, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
  • Peripherals: DMA
  • Architecture: MCU, FPGA
  • MCU RAM: 256KB
  • FPGA: Kintex-7, 444K logic cells
  • Estimated EOL Date: 2026
  • Supply and Demand Status: Limited
