734-203

Part No 734-203
Manufacturer WAGO Corporation
Catalog Headers, Plugs and Sockets
Description 1-CONDUCTOR FEMALE PLUG; 100% PR / 3 Position Terminal Block Plug, Female Sockets 0.150" (3.81mm) 180° Free Hanging (In-Line)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Terminal Blocks - Headers, Plugs and Sockets
Mfr WAGO Corporation
Series MCSMINI
Package Box
Product Status Active
Type Plug, Female Sockets
Number of Positions 3
Positions Per Level 3
Number of Levels 1
Pitch 0.150" (3.81mm)
Header Orientation -
Plug Wire Entry 180°
Termination Style Screwless - Push-In Spring
Mounting Type Free Hanging (In-Line)
Current - IEC 10A
Voltage - IEC 320 V
Current - UL 10 A
Voltage - UL 300 V
Wire Gauge or Range - AWG 14-28 AWG
Wire Gauge or Range - mm² 0.08-1.5mm²
Color Orange
Temperature Range - Operating -60°C ~ 100°C
Contact Mating Finish Tin
Features Retention Latches (Non-Wire Side)
Material Flammability Rating UL94 V-0
Ingress Protection -
Screw Size -
Torque - Screw -
Wire Strip Length 6-7mm
Contact Material Copper Alloy
Housing Material Polyamide (PA66), Nylon 6/6
Contact Tail Length -
Insulation Height 0.528" (13.40mm)
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 1364633-734-203
Ultra Librarian 3D Model Ultra Librarian 734-203 CAD Model

Description

The 734-203 is a plug terminal block manufactured by WAGO Corporation.

  • Features: Female Sockets and Retention Latches on the Non-Wire Side
  • Installation: Free-Hanging (In-Line)
  • Color: Orange
  • Pitch: 0.150" (3.81mm)
  • Positions: Up to 3
  • Insulation Height: 0.528" (13.40mm)
  • Contact Material: Copper Alloy
  • Termination Style: Screwless Push-In Spring
  • Current Rating (IEC and UL): 10A
  • Voltage Rating (UL): 300V
  • Voltage Rating (IEC): 320V
  • HTSUS Code: 8536.90.4000
  • ECCN Classification: EAR99
  • Wire Sizes: 14-28 AWG (0.08-1.5mm²)
  • Wire Strip Length: 6-7mm
