TCLT1003

Name: TCLT1003
Brand: Vishay
SKU: 360238
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TCLT1003
Manufacturer	Vishay
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISOLATR 5KV TRANSISTOR 4-SOP
Datasheet	TCLT1003 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	5000Vrms
Minimum DC Current Transfer Ratio	100% @ 10mA
Maximum DC Current Transfer Ratio	200% @ 10mA
Switching Turn-On and Turn-Off Time	6μs, 5μs
Rise and Fall Time	3μs, 4.7μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	70V
Channel Output Current	50mA
Forward Voltage	1.25V
Continuous forward current- Max	60mA
Vce Saturation (Max)	300mV
Temperature Range - Operating	-55°C to 100°C
Mounting	SMD (SMT)
Case / Package	4-SOP (2.54mm)
Win Source Part Number	032016-TCLT1003
Family Name	TCLT10
Introduction Date	September 27, 2005
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2022
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian TCLT1003 CAD Model

Description

The Vishay TCLT1003 is an isolator manufactured by Vishay.

Mounting: surface-mount device
Package: 4-SOP (2.54mm)
Minimum DC Current Transfer Ratio: 100% @ 10mA
Maximum DC Current Transfer Ratio: 200% @ 10mA
Switching Turn-On Time: 6μs
Switching Turn-Off Time: 5μs
Rise Time: 3μs
Fall Time: 4.7μs
Isolation Voltage: 5000Vrms
Maximum Output Voltage: 70V
