Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer TT Electronics/BI Magnetics
Packaging Reel
Type Invasive
Inductance 2mH
DC Resistance (DCR) 5mOhm Primary, 5.5Ohm Secondary
Mounting Style SMD
Dimension 0.320" L x 0.283" W (8.13mm x 8.20mm)
Height - Seated (Maximum) 0.210" (5.33mm)
Termination Style Gull Wing
Manufacturer Pack Quantity 750
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809132-HM33-10100LFTR
Ultra Librarian 3D Model Ultra Librarian HM33-10100LFTR CAD Model

Description

This electronic component is a type of invasive inductor manufactured by TT Electronics/BI Magnetics.

  • Inductance: 2mH
  • DC Resistance (DCR): 5mOhm primary, 5.5Ohm secondary
  • Dimension: 0.320" L x 0.283" W (8.13mm x 8.20mm)
  • Height: 0.210" (5.33mm)
  • MSL Level: 1 (Unlimited)
  • ET (Volt-Time): -
