TMC2660-PA-T Real Image1 TMC2660-PA-T Real Image2 TMC2660-PA-T Real Image3 TMC2660-PA-T Real Image4
Same model may have multiple batches, images only for reference.
TMC2660-PA-T Real Image1 TMC2660-PA-T Real Image2 TMC2660-PA-T Real Image3 TMC2660-PA-T Real Image4
TMC2660-PA-T Real Image1 TMC2660-PA-T Real Image2 TMC2660-PA-T Real Image3 TMC2660-PA-T Real Image4
Same model may have multiple batches, images only for reference.

TMC2660-PA-T

Part No TMC2660-PA-T
Manufacturer Trinamic Motion Control GmbH
Catalog PMIC - Motor Drivers, Controllers
Description IC MTR DRV BIPOLAR 3.3-5V 44PQFP
Datasheet
TMC2660-PA-T Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Trinamic Motion Control GmbH
Series stallGuard2™
Package Tape & Reel
Product Status Discontinued
Motor Type - Stepper Bipolar
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (4)
Interface SPI, Step/Direction
Technology Power MOSFET
Step Resolution 1 ~ 1/256
Applications General Purpose
Current - Output 2.8A
Voltage - Supply 3.3V ~ 5V
Voltage - Load 9V ~ 30V
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 44-LQFP
Supplier Device Package 44-PQFP (10x10)
Base Product Number TMC2660
Standard Package 1,500 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 851154-TMC2660-PA-T
Ultra Librarian 3D Model Ultra Librarian TMC2660-PA-T CAD Model

Description

The TMC2660-PA-T is a fully integrated motor driver IC designed for general-purpose applications from Trinamic Motion Control GmbH.

  • Series: stallGuard2™
  • Output Configuration: Half Bridge
  • Application: General Purpose
  • Technology: Power MOSFET
  • Output Current: 2.8A
  • Step Resolution: 1/256
  • Interface: SPI, Step/Direction
  • Motor Type: Bipolar Stepper
  • Voltage - Load: 9V ~ 30V
  • Number of Outputs: 4
  • Mounting Type: Surface Mount
  • Package / Case: 44-LQFP
  • Operating Temperature: -40°C ~ 125°C
  • Lifecycle Status: Discontinued
