TLP291-4GB

Name: TLP291-4GB
Brand: Toshiba Semiconductor and Storage
SKU: 370334
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP291-4GB
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	Optocoupler DC-IN 4-CH Transistor DC-OUT 16-Pin SO / Optoisolator Transistor Output 2500Vrms 4 Channel 16-SO
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators
Family	Optoisolators - Transistor, Photovoltaic Output
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel(TR)
Number of Channels	4
Voltage - Isolation	2500Vrms
Current Transfer Ratio (Min)	100% @ 5mA
Current Transfer Ratio (Max)	400% @ 5mA
Turn On / Turn Off Time (Typ)	3μs, 3μs
Rise / Fall Time (Typ)	2μs, 3μs
Input Type	DC
Output Type	Transistor
Voltage - Output (Max)	80V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.2V
Current - DC Forward (If) (Max)	50mA
Vce Saturation (Max)	400mV
Operating Temperature Range	-55°C ~ 110°C
Mounting Style	SMD/SMT
Package	16-SOIC (0.179", 4.55mm Width)
Manufacturer Device Package	16-SO
Win Source Part Number	218174-TLP291-4GB
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	TLP291-4
Introduction Date	March 20, 2012
ECCN	EAR99
Country of Origin	Thailand
Estimated EOL Date	2026
Ultra Librarian 3D Model	Ultra Librarian TLP291-4GB CAD Model

Alternative Products

Description

The Toshiba Semiconductor and Storage TLP291-4GB is a high-quality optoisolator that is perfect for a wide range of applications.

Family Name: TLP291-4
Package: Reel - TR
Dimension: 16-SOIC (0.179", 4.55mm Width)
Output Type: Transistor
Input Type: DC
Current - DC Forward (If) (Max): 50mA
Voltage - Forward (Vf) (Typ): 1.2V
Current Transfer Ratio (Min): 100% @ 5mA
Voltage - Output (Max): 80V
Current Transfer Ratio (Max): 400% @ 5mA
Turn On / Turn Off Time (Typ): 3μs, 3μs
Supply and Demand Status: Limited
