TLP280-4(GB-TP,J,F Toshiba Semiconductor and Storage TLP280-4(GB-TP,J,F real image
Same model may have multiple batches, images only for reference.
TLP280-4(GB-TP,J,F Toshiba Semiconductor and Storage TLP280-4(GB-TP,J,F real image
TLP280-4(GB-TP,J,F Toshiba Semiconductor and Storage TLP280-4(GB-TP,J,F real image
Same model may have multiple batches, images only for reference.

TLP280-4(GB-TP,J,F

Part No TLP280-4(GB-TP,J,F
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 2.5KV 4CH TRANS 16-SOP
Datasheet
TLP280-4(GB-TP,J,F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Cut Reel
Status Obsolete(EOL)
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SOP
Win Source Part Number 1108894-TLP280-4(GB-TP,J,F
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TLP280-4(GB-TP,J,F CAD Model

Description

The Toshiba TLP280-4(GB-TP,J,F is a high-performance SMD (SMT) isolator that is ideal for use in a wide range of applications.

  • Manufacturer: Toshiba
  • Isolation Voltage: 2500Vrms
  • Channels: 4
  • Supply and Demand: Sufficient
