TLP2301(TPL,E Toshiba Semiconductor and Storage TLP2301(TPL,E real image
Same model may have multiple batches, images only for reference.
TLP2301(TPL,E Toshiba Semiconductor and Storage TLP2301(TPL,E real image
TLP2301(TPL,E Toshiba Semiconductor and Storage TLP2301(TPL,E real image
Same model may have multiple batches, images only for reference.

TLP2301(TPL,E

Part No TLP2301(TPL,E
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS 6-SO 4 LEAD
Datasheet
TLP2301(TPL,E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 50% @ 1mA
Maximum DC Current Transfer Ratio 600% @ 1mA
Input Type DC
Output Type Transistor
Maximum Output Voltage 40V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 6-SO, 4 Lead
Win Source Part Number 1056077-TLP2301(TPL,E
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TLP2301(TPL,E CAD Model

Description

The Toshiba Semiconductor and Storage TLP2301(TPL,E is a single-channel transistor output optocoupler.

  • Input Type: DC input
  • Maximum Output Voltage: 40V
  • Channel Output Current: 50mA
  • Isolation Voltage: 3750Vrms
  • Minimum DC Current Transfer Ratio: 50% @ 1mA
  • Package: 6-SO, 4 Lead
  • Application: isolator applications
