TLP124 Toshiba Semiconductor and Storage TLP124 Real Image
Same model may have multiple batches, images only for reference.
TLP124 Toshiba Semiconductor and Storage TLP124 Real Image
TLP124 Toshiba Semiconductor and Storage TLP124 Real Image
Same model may have multiple batches, images only for reference.

TLP124

Part No TLP124
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description DC-IN 1-CH Transistor DC-OUT 4-Pin MFSOP Tube / OPTOISOLTR 3.75KV TRANS 6-MFSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Tube/Rail
Status Not For New Designs
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 1mA
Maximum DC Current Transfer Ratio 1200% @ 1mA
Switching Turn-On and Turn-Off Time 10μs, 8μs
Rise and Fall Time 8μs, 8μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 6-MFSOP, 4 Lead
Win Source Part Number 093116-TLP124
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TLP124
Introduction Date February 27, 1998
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian TLP124 CAD Model

Description

The Toshiba Semiconductor and Storage TLP124 is an isolator with a maximum output voltage of 80V and a channel output current of 50mA.

  • Minimum DC current transfer ratio: 100% @ 1mA
  • Maximum DC current transfer ratio: 1200% @ 1mA
  • Switching turn-on time: 10μs
  • Switching turn-off time: 8μs
  • Rise time: 8μs
  • Fall time: 8μs
  • Operating temperature range: -55°C to 100°C
  • Package: 6-MFSOP, 4 Lead package
  • Availability: in the open market. It is not for new designs.
