TCS40DLR,LF Toshiba Semiconductor and Storage TCS40DLR,LF real image TCS40DLR,LF real image11288 TCS40DLR,LF real image11289
Same model may have multiple batches, images only for reference.
TCS40DLR,LF Toshiba Semiconductor and Storage TCS40DLR,LF real image TCS40DLR,LF real image11288 TCS40DLR,LF real image11289
TCS40DLR,LF Toshiba Semiconductor and Storage TCS40DLR,LF real image TCS40DLR,LF real image11288 TCS40DLR,LF real image11289
Same model may have multiple batches, images only for reference.

TCS40DLR,LF

Part No TCS40DLR,LF
Manufacturer Toshiba Semiconductor and Storage
Catalog Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH OMNIPOLAR SOT23F
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Purpose Omnipolar Switch
Technology Hall Effect
Polarization Either
Sensing Range ±4.4mT Trip, ±0.9mT Release
Testing Conditions 25°C
Supply Voltage - Operating 2.3 V to 5.5 V
Current - Supply (Max) 1.6mA (Typ)
Current - Output (Max) 5mA
Output Type Open Drain
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package SOT-23F
Win Source Part Number 1106454-TCS40DLR,LF
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TCS40DLR,LF CAD Model

Description

The Toshiba Semiconductor and Storage TCS40DLR,LF is a hall effect sensor used as an omnipolar switch.

  • Manufacturer: Toshiba Semiconductor and Storage
  • Type: Hall Effect Sensor
  • Function: Omnipolar Switch
  • Output Type: Open Drain
  • Polarization: Either Way
  • Sensing Range: ±4.4mT trip and ±0.9mT release
  • Maximum Current Supply: 1.6mA
  • Maximum Output Current: 5mA
  • Supply Voltage Range: 2.3 V to 5V
  • Market Status: Sufficient supply and demand
