Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Output Isolation Isolated
Internal Switch(s) No
Topology Flyback
Voltage - Start Up 21V
Supply Voltage 9 V ~ 35 V
Frequency - Switching 680Hz ~ 100kHz
Fault Protection Current Limiting, Over Voltage
Operating Temperature Range -40°C ~ 125°C (TJ)
Package 8-SOIC (0.154", 3.90mm Width) 7 leads
Manufacturer Package 7-SOIC
Mounting SMD
Win Source Part Number 1276302-UCC28710DR
Manufacturer Homepage www.ti.com
Family Name UCC28710
Introduction Date November 15, 2012
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management, Consumer Electronics, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian UCC28710DR CAD Model

Description

The UCC28710DR from Texas Instruments is a highly efficient, off-line flyback switcher with low standby power designed for use in power adapters and auxiliary power supplies. This component is part of TI's extensive range of power management integrated circuits, meticulously engineered to deliver reliable and energy-conserving power conversion.

The UCC28710DR operates by modulating its switching frequency along with primary-side regulation (PSR) to accurately maintain output voltage without the need for an optocoupler. This feature simplifies the design and increases reliability by reducing the number of external components required. The device's quasi-resonant mode of operation improves efficiency by minimizing switching losses and reducing EMI, making it an excellent choice for applications that demand high efficiency and low noise operation.

One of the standout features of the UCC28710DR is its ability to achieve very low no-load power consumption, typically less than 30mW, which exceeds the requirements of energy efficiency regulations such as ENERGY STAR and the European Code of Conduct. This makes it an ideal choice for eco-conscious designs where standby power needs to be minimized.

Other important features include an integrated 700V power MOSFET, which allows for a wide range of input voltages and improved power handling. The device also offers multiple protection features such as overcurrent, overvoltage, and thermal shutdown, which help to ensure the safety and longevity of the end application.

The UCC28710DR comes in a compact SOIC-7 package, making it suitable for space-constrained applications. Its versatility makes it a great candidate for a variety of products including smartphone and tablet adapters, appliance power supplies, and smart meter auxiliary power supplies.

Overall, the UCC28710DR is a testament to Texas Instruments' commitment to providing advanced, energy-efficient power solutions that meet the ever-increasing demands of modern electronic devices.
