TPS61161ADRVT from Texas Instruments

The TPS61161ADRVT is a high-quality, efficient, and versatile LED driver IC designed and manufactured by Texas Instruments (TI), a leader in semiconductor solutions. This driver is specifically engineered to provide a constant current output, which is ideal for driving a string of high-brightness LEDs in various lighting applications. Its compact form factor, the 6-pin SON package, makes it suitable for space-constrained applications.

The TPS61161ADRVT operates over a wide input voltage range of 3 V to 18 V, which allows it to be used in systems powered by a variety of sources, from single-cell lithium-ion batteries to multi-cell battery packs or regulated power supplies. The device offers a fixed frequency of 1.2 MHz, which enables the use of small external components, thus reducing the overall solution size and cost.

This LED driver integrates a 40-V switch FET, which means it can handle the high voltages required for several LED series connections. It is designed with an internal soft start, which limits inrush current and extends LED life by providing a gradual increase in current to the LEDs during power-up.

One of the key features of the TPS61161ADRVT is its excellent efficiency, which is enhanced by its integrated 1.5-A switch current limit and low quiescent current. Additionally, the device supports pulse width modulation (PWM) dimming, which gives designers the flexibility to adjust brightness levels according to the needs of their specific applications. This dimming capability is essential for applications that require varying light intensity, such as backlighting in consumer electronics, automotive lighting, and general illumination.

For safety and reliability, the TPS61161ADRVT includes overvoltage and thermal shutdown protection features. These protections ensure that the device and the LEDs it drives are safeguarded against potential damage from electrical or thermal over-stress conditions.

Overall, the TPS61161ADRVT by Texas Instruments is an excellent choice for designers looking for a high-performance, reliable, and easy-to-use LED driver solution that can be seamlessly integrated into a wide range of lighting applications.
