The SN75372DR is a high-performance dual peripheral driver designed and manufactured by Texas Instruments. This integrated circuit is engineered to provide reliable interface solutions for a wide range of digital electronics. It is particularly well-suited for driving inductive loads such as relays, solenoids, and other high-current/high-voltage devices.

Key Features

• Dual Independent Channels: The SN75372DR features two separate driver channels which can be used to control two different loads or combined for higher power applications.
• High Voltage Outputs: With an output voltage range capable of handling up to 30V, this driver can easily manage the demands of most high-voltage applications.
• High Current Drive: Each channel can source up to 500 mA of current, making it suitable for driving a variety of inductive loads.
• Input Compatible with Various Logic Levels: The inputs are compatible with standard TTL and CMOS levels, ensuring that the SN75372DR can be driven by a wide range of control logic circuits.
• Protection Features: The device includes built-in clamp diodes for inductive transient suppression, which protects the driver and enhances system reliability.
• Wide Operating Temperature Range: It operates effectively across a broad temperature range from 0°C to 70°C, accommodating diverse environmental conditions.

Applications

The SN75372DR is versatile and can be used in various applications, including:

• Relay and Solenoid Drivers
• Motor Controllers
• Line Drivers
• Hammer Drivers for Printers
• LED Displays and Indicators

Physical Characteristics

The SN75372DR comes in an SOIC-8 (Small Outline Integrated Circuit) package, which is ideal for space-constrained applications. Its compact form factor and surface-mount design make it easy to incorporate into modern PCB layouts.

Ordering Information

For ordering, the product is available under the part number SN75372DR. It is supplied in tape and reel packaging, facilitating efficient assembly during mass production.

Note: For detailed specifications, application circuits, and safety information, refer to the official Texas Instruments datasheet for the SN75372DR.
