The SN74AUP1G14DRYR is a high-performance, single-gate logic inverter from Texas Instruments, designed for optimal power and speed in a compact footprint. This device is part of the advanced ultra-low power (AUP) series, which is engineered to operate with extremely low power consumption while maintaining high-speed operation, making it an ideal choice for power-sensitive applications.

Key Features

• Low Power Consumption: With an ultra-low static power consumption and a dynamic power that scales with frequency, the SN74AUP1G14DRYR is perfect for battery-operated and power-conscious designs.
• Advanced Design: This component is built using Texas Instruments' advanced silicon-gate CMOS technology, which provides a significant reduction in power consumption compared to conventional CMOS devices.
• High-Speed Operation: Despite its low power usage, the SN74AUP1G14DRYR does not compromise on speed, offering fast switching characteristics suitable for a variety of high-speed applications.
• Single Schmitt-Trigger Inverter: The device features a single inverter with a Schmitt-trigger input, which provides a hysteresis that enhances noise immunity and allows for slow input transition.
• Wide Operating Voltage Range: It operates across a broad voltage range from 0.8V to 3.6V, accommodating a range of logic levels and making it versatile for interfacing with other logic families.
• Compact Package: The SN74AUP1G14DRYR comes in a small 6-pin SON package, which is ideal for space-constrained applications.

Applications

The device is designed for use in a variety of applications where power efficiency is critical. These include portable and battery-powered devices, wearables, mobile phones, and other handheld consumer electronics. Additionally, it is suitable for use in control systems, medical devices, and any other systems where low-voltage operation is essential.

Quality and Reliability

As with all Texas Instruments products, the SN74AUP1G14DRYR is manufactured to the highest quality standards, ensuring reliable performance in even the most demanding conditions. The device is RoHS compliant and is designed for long-term dependability.
