REF3012AIDBZTG4 Real Image REF3012AIDBZTG4 real image REF3012AIDBZTG4 Real Image
Same model may have multiple batches, images only for reference.
REF3012AIDBZTG4 Real Image REF3012AIDBZTG4 real image REF3012AIDBZTG4 Real Image
REF3012AIDBZTG4 Real Image REF3012AIDBZTG4 real image REF3012AIDBZTG4 Real Image
Same model may have multiple batches, images only for reference.

REF3012AIDBZTG4

Part No REF3012AIDBZTG4
Manufacturer Texas Instruments
Catalog PMIC - Voltage Reference
Description IC VREF SERIES 1.25V SOT23-3
Datasheet
REF3012AIDBZTG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 1.25V
Output Current 25mA
Tolerance ±0.2%
Temperature Coefficient 75ppm/°C
Noise - 0.1Hz to 10Hz 14μVp-p
Noise - 10Hz to 10kHz 42μVrms
Voltage - Input 1.8 V to 5.5 V
Operating Supply Current 50μA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 210727-REF3012AIDBZTG4
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian REF3012AIDBZTG4 CAD Model

Description

The REF3012AIDBZTG4 from Texas Instruments is a high-quality, low-power, voltage reference device that offers excellent precision and stability.

  • Output Voltage: Fixed 1.25V output voltage.
  • Accuracy: +/-0.2%.
  • Supply Current: Maximum 100µA.
  • Operating Temperature Range: -40°C to +125°C.
  • Package: Small SOT-23 package.
  • Input Voltage Range: 2.7V to 5.5V.
  • Output Current: 10mA.
