Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 021518-MAX3232EIDR
Family Name MAX3232E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Automation & Process Control, HVAC, Communications & Networking
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian MAX3232EIDR CAD Model

Description

The MAX3232EIDR is a high-quality, versatile integrated circuit (IC) product designed and manufactured by Texas Instruments, a globally recognized leader in the semiconductor industry.

  • Series: MAX3232
  • Voltage Range: 3.0 V to 5.5 V
  • Data Rate: 250 kbps
  • Auto-Power-Down: Yes
  • Drivers: 2
  • Receivers: 2
  • Driver Output Swing: ±5.3-V with a 3.0-V to 5.5-V input
  • Receiver Input: Up to ±30-V
  • Package: 16-pin SOIC
  • ESD Protection: Up to ±15kV
  • Compliance: RoHS Compliant
