Product Overview: LMZ23603TZE/NOPB

The LMZ23603TZE/NOPB is a high-efficiency, easy-to-use, 3A power module from Texas Instruments designed for a wide range of applications. This power solution integrates a DC/DC converter, inductor, and passives into a compact, low-profile package, making it ideal for space-constrained applications.

Key Features

• Input Voltage Range: The module supports an input voltage range of 6V to 36V, which caters to a variety of industrial and communication power supply requirements.
• Output Voltage: The output voltage is adjustable from 0.8V to 6V, allowing for flexibility in design for different load requirements.
• High Efficiency: The LMZ23603TZE/NOPB is designed to offer high efficiency, which can exceed 90% under certain conditions, thereby reducing power loss and improving system performance.
• Integrated Shielded Inductor: The inclusion of an integrated shielded inductor ensures minimal electromagnetic interference (EMI) and simplifies the design process.
• Thermal Performance: The power module is encapsulated in a thermally enhanced package, which aids in heat dissipation for better thermal performance and reliability.
• Protection Features: It includes over-temperature, over-current, and under-voltage lockout protections, providing a robust solution for sensitive applications.

Applications

The LMZ23603TZE/NOPB is versatile and can be used in a variety of applications, including:

• Telecommunications Equipment
• Industrial Controls and Automation
• Test and Measurement Systems
• Consumer Electronics

Quality and Reliability

As with all Texas Instruments products, quality and reliability are at the forefront. The LMZ23603TZE/NOPB is lead-free, RoHS compliant, and designed to meet the stringent requirements of the industrial market. The NOPB designation indicates that the product is available in a lead-free, environmentally friendly package.
