Introducing the ISO7760DBQ from Texas Instruments

The ISO7760DBQ is a high-performance, six-channel digital isolator from Texas Instruments (TI), designed to offer robust signal isolation for a wide range of applications. This advanced component is ideal for systems that require the transfer of digital signals across isolation barriers to ensure integrity and isolation from high voltage, noise, and ground loops.

Key Features

• Robust Isolation: With a capability to withstand isolation voltages of up to 5000 Vrms for 1 minute, the ISO7760DBQ ensures protection against high-voltage spikes and surges, making it suitable for industrial, medical, and other sensitive applications.
• High Data Integrity: The device features a low propagation delay and a data rate of up to 100 Mbps, ensuring fast and accurate signal transmission without compromising data integrity.
• Low Power Consumption: Designed with energy efficiency in mind, the ISO7760DBQ operates with a low power consumption, making it ideal for power-sensitive applications.
• Wide Operating Temperature Range: The device can operate over a wide temperature range from -40°C to +125°C, ensuring reliable performance in extreme conditions.
• Fail-Safe Design: The ISO7760DBQ incorporates a fail-safe design that ensures a logic-high output when inputs are inactive, enhancing system safety.

Applications

The versatility of the ISO7760DBQ makes it an excellent choice for various applications, including:

• Industrial automation and control systems
• Medical equipment with stringent isolation requirements
• Isolated data communication in motor drives
• Renewable energy systems and battery management
• Isolated interface power supplies

Product Specifications

The ISO7760DBQ comes in a compact 16-pin SSOP (DBQ) package that is conducive to space-constrained applications. It provides six independent isolation channels with four forward and two reverse-direction channels. The device is characterized for operation from a single 2.25 V to 5.5 V supply, affording it great flexibility in various design architectures.

With the ISO7760DBQ, Texas Instruments continues to deliver on its promise of high-quality, reliable components that meet the evolving needs of modern electronics. Whether you're designing a new system or upgrading an existing one, the ISO7760DBQ is an excellent choice for ensuring signal integrity and isolation.
