Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 3
Inputs - Side 1/Side 2 2/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002057-ISO7231CDWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISO7231CDWR CAD Model

Description

The ISO7231CDWR is a high-performance, triple-channel digital isolator product from Texas Instruments, a renowned leader in semiconductor technology.

  • Insulation Material: Silicon dioxide (SiO2)
  • Channels: Three isolation channels (two forward, one reverse)
  • Data Rate: Up to 150 Mbps
  • Propagation Delay: 21 ns
  • Supply Voltage Range: 2.7V to 5.5V
  • Common-Mode Transient Immunity: More than 50 kV/µs
  • Power Consumption: Less than 5 mW per channel @ 1 Mbps
  • Package: Compact 16-pin SOIC package
  • Temperature Range: -40°C to +125°C
