ISO7231CDW Real Image ISO7231CDW Real Image
Same model may have multiple batches, images only for reference.
ISO7231CDW Real Image ISO7231CDW Real Image
ISO7231CDW Real Image ISO7231CDW Real Image
Same model may have multiple batches, images only for reference.

ISO7231CDW

Part No ISO7231CDW
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 16SOIC
Datasheet
ISO7231CDW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 3
Inputs - Side 1/Side 2 2/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 082549-ISO7231CDW
Family Name ISO7231
Introduction Date October 01, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISO7231CDW CAD Model

Description

The ISO7231CDW is a high-performance, triple-channel digital isolator product manufactured by Texas Instruments.

  • Data Rate: Up to 150Mbps
  • Channels: Three channels (two in one direction, one in the opposite direction)
  • Isolation Technology: Capacitive isolation technology
  • Breakdown Voltage: 2.5kVrms for one minute per UL1577
  • Power Consumption: Low power consumption
  • Quiescent Current: 1.5mA per channel @ 25°C
  • Temperature Range: -40°C to +125°C
  • Package: Wide-body SOIC-16 (DW) package
