Products specifications

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Texas Instruments
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 2
Voltage - Reverse Standoff (Typ) 3.6V (Max)
Voltage - Breakdown (Min) 4.5V
Voltage - Clamping (Max) @ Ipp 6.5V (Typ)
Current - Peak Pulse (10/1000µs) 25A (8/20µs)
Power - Peak Pulse 170W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 4.5pF @ 1MHz
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Supplier Device Package SOT-23-5
Base Product Number ESDS312
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 851351-ESDS312DBVR
Ultra Librarian 3D Model Ultra Librarian ESDS312DBVR CAD Model

Description

The ESDS312DBVR is a state-of-the-art ESD protection device designed by Texas Instruments, a renowned leader in the semiconductor industry. This product is specifically engineered to safeguard sensitive electronic components against electrostatic discharge (ESD), which can cause irreparable damage to electronic circuits. The device is particularly well-suited for high-speed data lines, offering robust protection while maintaining signal integrity.

Key Features

  • Low Capacitance: The ESDS312DBVR boasts ultra-low capacitance, typically at 0.6 pF, which is ideal for maintaining the fidelity of high-speed signals without significant attenuation or distortion.
  • High ESD Protection: It offers excellent ESD protection, withstanding ESD strikes exceeding the IEC 61000-4-2 (Level 4) standard, ensuring devices are safe from common electrostatic threats.
  • Small Form Factor: Housed in a small SOT-23 (DBV) package, the ESDS312DBVR is perfect for applications where board space is at a premium, without compromising on protection capabilities.
  • Low Clamping Voltage: The device features a low clamping voltage, which provides enhanced protection for sensitive circuits by limiting the voltage spike during an ESD event.
  • Bidirectional Protection: It offers bidirectional transient voltage suppression, which means it can protect circuits from ESD pulses entering from either direction along the protected line.

Applications

The versatility of the ESDS312DBVR makes it suitable for a wide range of applications, including:

  • USB interfaces
  • HDMI and DisplayPort interfaces
  • Thunderbolt ports
  • Antenna lines
  • High-speed data lines in consumer electronics
  • Mobile handsets and portable devices

Quality and Reliability

Texas Instruments is committed to delivering high-quality products, and the ESDS312DBVR is no exception. It is manufactured using industry-leading processes and subjected to rigorous testing to ensure it meets the highest standards of performance and reliability. Protect your sensitive electronics with the confidence that comes from using a product from a trusted industry leader.
