DCP020505U Real Image DCP020505U real image3226 DCP020505U real image3227 DCP020505U Real Image1 DCP020505U Real Image2 DCP020505U Real Image3 DCP020505U Real Image4 DCP020505U Real Image5 DCP020505U Real Image6 DCP020505U Real Image7
Same model may have multiple batches, images only for reference.
DCP020505U Real Image DCP020505U real image3226 DCP020505U real image3227 DCP020505U Real Image1 DCP020505U Real Image2 DCP020505U Real Image3 DCP020505U Real Image4 DCP020505U Real Image5 DCP020505U Real Image6 DCP020505U Real Image7
DCP020505U Real Image DCP020505U real image3226 DCP020505U real image3227 DCP020505U Real Image1 DCP020505U Real Image2 DCP020505U Real Image3 DCP020505U Real Image4 DCP020505U Real Image5 DCP020505U Real Image6 DCP020505U Real Image7
Same model may have multiple batches, images only for reference.

DCP020505U

Part No DCP020505U
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description IC REG ISOLATED 5V 0.4A 12SOP
Datasheet
DCP020505U Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series DCP02
Packaging Tube
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 5V
Current - Output (Max) 400mA
Power (Watts) - Manufacture Series 2W
Voltage - Isolation 1kV (1000V)
Applications ITE (Commercial)
Features OTP
Mounting Style SMD/SMT
Package 12-SOIC (0.295", 7.50mm Width)
Size / Dimension 0.71" L x 0.30" W x 0.10" H (18.1mm x 7.6mm x 2.7mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 80%
Power (Watts) - Max 90mW
Win Source Part Number 013857-DCP020505U
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DCP020505U CAD Model

Description

Description

The DCP020505U is a versatile, high-efficiency isolated DC-DC converter engineered for various power conversion needs. With its robust design, this module delivers consistent power supply solutions for several electronic systems.

Features and Benefits

  • 80% efficiency rate for optimal performance
  • Low isolation capacitance for improved stability
  • Integrated short-circuit protection
  • Compact SIP packaging for simplified installation
  • Operation over wide temperature ranges from -40°C to 85°C

Applications

  • Industrial control panels
  • Communications infrastructure
  • Microcontroller-based systems
  • Voltage regulation projects
  • Sensor interfaces

Additional Details

The DCP020505U’s durable construction and array of protective features make it an excellent choice for ensuring the reliability and longevity of critical electronic applications.
