SMD200F-2 Real Image SMD200F-2 Real Image
Same model may have multiple batches, images only for reference.
SMD200F-2 Real Image SMD200F-2 Real Image
SMD200F-2 Real Image SMD200F-2 Real Image
Same model may have multiple batches, images only for reference.

SMD200F-2

Part No SMD200F-2
Manufacturer TE Connectivity
Catalog PTC Resettable Fuses
Description POLYSWITCH 2.00A HOLD SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TE Connectivity
Standard Package 1
Category Circuit Protection
Family PTC Resettable Fuses
Series PolySwitch
Packaging Reel
Voltage - Max 15V
Current - Max 40A
Current - Hold (Ih) (Max) 2A
Current - Trip (It) 4A
R Min/Max 0.050 ~ 0.125 Ohm
Time to Trip 12s
Package 2-SMD
Catalog PolySwitch Surface Mount
Win Source Part Number 084162-SMD200F-2
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SMD200F-2 CAD Model

Description

The TE Connectivity 084162-SMD200F-2 is a PTC resettable fuse belonging to the PolySwitch series.

  • Maximum Voltage Rating: 15V
  • Maximum Current Rating: 40A
  • Current Hold (Ih): 2A
  • Current Trip (It): 4A
  • R Min/Max: 0.050 ~ 0.125 Ohm
  • Time to Trip: 12s
