Same model may have multiple batches, images only for reference.
5787190-8 Real Image
Same model may have multiple batches, images only for reference.

5787190-8

Part No 5787190-8
Manufacturer TE Connectivity
Catalog D-Sub, D-Shaped Connectors - Assemblies
Description CONN D-TYPE RCPT 80POS R/A SLDR / 80 Position D-Type Receptacle, Female Sockets Connector
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>D-Sub, D-Shaped Connectors>D-Sub Connector Assemblies
Manufacturer TE Connectivity AMP Connectors
Packaging Tube
Connector Style D-Type
Connector Type Receptacle, Female Sockets
Number of Positions 80
Number of Rows 2
Mounting Board Edge, Through Hole, Right Angle
Shell Size, Connector Layout 0.050 Pitch x 0.100 Row to Row
Contact Type Signal
Flange Feature Housing/Shell (2-56); Latchblocks, Rails
Termination Solder
Shell Material, Finish Steel, Nickel Plated
Contact Finish Gold
Material Flammability Rating UL94 V-0
Current Rating (Amps) 1A
Backset Spacing 0.146" (3.71mm)
Features Shielded
Voltage Rating 30V
Color Black
Dielectric Material Thermoplastic
Contact Material Phosphor Bronze
Temperature Range - Operating -55°C ~ 105°C
Base Product Number 5787190
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Part Number A31818,57871908,2266-5787190-8
Standard Package 7
Win Source Part Number 1333177-5787190-8
Ultra Librarian 3D Model Ultra Librarian 5787190-8 CAD Model

Description

The TE Connectivity AMP Connectors 5787190-8 is a D-sub connector assembly with two rows of 80 female sockets.

  • Shielded: Yes
  • Color: Black
  • Voltage Rating: 30V
  • Current Rating: 1A
  • Mounting: Board Edge, Through Hole, and Right Angle
  • Housing/Shell Material: Steel
  • Housing/Shell Finish: Nickel Plated
  • Packaging: Tube
  • Standard Package: 7
  • MSL Level: 1 (Unlimited)
  • HTSUS: 8536.69.4040
  • RoHS: Compliant
