5-146128-1 Real Image
Same model may have multiple batches, images only for reference.

5-146128-1

Part No 5-146128-1
Manufacturer TE Connectivity
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 3POS 2.54MM / Connector Header Surface Mount 3 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity AMP Connectors
Series AMPMODU Mod II
Package Bulk
Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 3
Number of Rows 1
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.230" (5.84mm)
Insulation Height 0.090" (2.29mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP)
Temperature Range - Operating -65°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A
Contact Finish Thickness - Post 100.0µin (2.54µm)
Base Product Number 146128
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-5-146128-1,5-146128-1-ND,A121367
Standard Package 73
Win Source Part Number 1038896-5-146128-1
Ultra Librarian 3D Model Ultra Librarian 5-146128-1 CAD Model

Description

The TE Connectivity AMP Connectors AMPMODU Mod II 3-position header is a male pin connector with a pitch of 0.100" (2.54mm).

  • Positions: 3
  • Pitch: 0.100" (2.54mm)
  • Current Rating: 3A
  • Contact Material: copper alloy
  • Application: board-to-board or cable-to-board
  • Packaging: bulk
  • Quantity: 73 units
  • Temperature Range: -65°C to 105°C
  • Insulation Material: liquid crystal polymer (LCP)
  • ROHS3 Compliant: Yes
  • Design: shrouded, unshrouded
