Part No 4-174904-2
Manufacturer TE Connectivity
Catalog Rectangular - Board to Board Connectors
Description CONN RCPT 12POS 0.049 TIN SMD  /  12 Position Receptacle Connector 0.049" (1.25mm) Surface Mount Tin
Datasheet
4-174904-2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr TE Connectivity AMP Connectors
Series Fine Pitch
Package Bulk
Connector Type Receptacle
Contact Type Forked
Style Board to Board
Number of Positions 12
Number of Positions Loaded All
Pitch - Mating 0.049" (1.25mm)
Number of Rows 2
Row Spacing - Mating 0.049" (1.25mm)
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 31.5µin (0.80µm)
Insulation Color Black
Insulation Height 0.134" (3.40mm)
Temperature Range - Operating -30°C ~ 105°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Current Rating (Amps) 0.5A
Voltage Rating 50V
Insulation Material Polyphenylene Sulfide (PPS)
Contact Shape Circular
Contact Material Phosphor Bronze
Base Product Number 174904
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Names -4-174904-2-SI,2266-4-174904-2
Standard Package 10,000
Win Source Part Number 1002502-4-174904-2
Ultra Librarian 3D Model Ultra Librarian 4-174904-2 CAD Model

Description

This is a Fine Pitch rectangular connector with a receptacle connector type and forked contact type. It has 12 positions loaded in 2 rows and is terminated with solder.

  • Connector Type: Rectangular, Fine Pitch
  • Receptacle Type: Yes
  • Contact Type: Forked
  • Positions Loaded: 12
  • Rows: 2
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Package: Bulk
  • Voltage Rating: 50V
  • Contact Material: Phosphor Bronze
  • Insulation Material: Polyphenylene Sulfide (PPS)
  • Board to Board Style: Yes
  • Pitch (Mating): 0.049 inches (1.25mm)
  • Contact Finish (Mating): Tin, 31.5μin (0.80μm)
  • Contact Finish (Post): Tin
  • Insulation Color: Black
  • Row Spacing (Mating): 0.049 inches (1.25mm)
  • Insulation Height: 0.134 inches (3.40mm)
  • Contact Shape: Circular
  • Operating Temperature: -30°C to 105°C
  • Current Rating: 0.5A
  • MSL Level: 1 (Unlimited)
  • HTSUS: 8536.69.4040
  • Manufacturer: TE Connectivity AMP Connectors
