Same model may have multiple batches, images only for reference.

1-1393092-8

Get a Quote

Part No	1-1393092-8
Manufacturer	TE Connectivity
Catalog	Signal Relays, Up to 2 Amps
Description	Electromechanical Relay 24VDC 475Ohm 10A 3PDT(35.6x35.5x57)mm Plug-In Industrial Relay
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Coil Current	50 mA
Coil Power	1.5 W
Coil Resistance	475 Ω
Coil Type	Non-Latching
Coil Voltage (DC)	24 V
Contact Current Rating	10 A
Contact Material	Silver
Contact Plating	Gold
Contact Voltage Rating (AC)	240 V
Current Rating	10 A
Dropout Voltage	2.4 V
ELV	Compliant
Height	57 mm
Lead Free	Not Applicable
Length	35.6108 mm
Max Operating Temperature	60 °C
Min Operating Temperature	-45 °C
Mount	Socket
Number of Pins	11
Operate Time	15 ms
Packaging	Bulk
Relay Type	General Purpose
Release Time	10 ms
RoHS	Compliant
Termination	Plug
Throw Configuration	3PDT
Weight	80.059053 g
Width	35.5 mm
Win Source Part Number	1226415-1-1393092-8
Categories	Signal Relays,Up to 2 Amps
Manufacturer	TE Connectivity
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian 1-1393092-8 CAD Model

Alternative Products

Description

The TE Connectivity 1226415-1-1393092-8 is a general purpose non-latching relay.

Coil Voltage (DC): 24 V
Contact Voltage Rating (AC): 240 V
Current Rating: 10 A
Contact Current Rating: 10 A
Relay Type: General Purpose
Coil Type: Non-Latching
Operate Time: 15 ms
Release Time: 10 ms
Coil Power: 1.5 W
Dropout Voltage: 2.4 V
Height: 57 mm
Width: 35.5 mm
Length: 35.6108 mm
Number of Pins: 11
Weight: 80.059053 g
RoHS Compliant: Yes
